The industry leader in evaluation printed circuit boards (PCB) for RF/Microwave, and Optical networking components
Electro-Photonics LLC designs simple and very useful test boards for evaluating RF/Microwave and Photonics components. We like to make design engineers’ jobs easier by offering test boards that simplify the process of evaluating passive and active components. You don't need to spend valuable CAD and engineering resources and wait 8-12 weeks to get your eval board.
Despite their “simplicity”, we all know that these boards can cost a lot of money and time. You know that it costs thousand of dollars to design and build a simple test board or RF fixture. First, your personal time, next the CAD operator, machine shop, hours on the phone with the board house, and 4-6 weeks lead time to receive parts – not to mention all the drawings and paperwork you must generate.
In addition, you may spin the board more than once - just because you missed a few vias!
RF/Microwave Evaluation Boards
Our unique 0402 RF eval board will help you evaluate in minutes many passive components up to 10GHz. An optimized through line, short, and open are included for quick de-embedding. Everything you need to evaluate any passive component is on one easy to use board.
